Viewing Head
|
Stereo Brinocular Viewing Head, Inclined at 45º
|
●
|
|
Eyepiece
|
Wide Field Eyepiece WF10X/F.N.22mm
|
●
|
|
Wide Field Eyepiece WF15X/F.N.16mm
|
○
|
|
Wide Field Eyepiece WF20X/F.N.12mm
|
○
|
|
Zoom Objective
|
0.67X-4.5X
|
●
|
|
Coarse Range
|
110mm
|
●
|
|
Working Distance
|
100mm
|
●
|
|
Interpupillary distance
|
54mm-76mm
|
●
|
|
Iris Diaphragm
|
with Aperture hole adjustable φ44mm-φ3mm
|
|
|
Illumination
|
Upper illumination:7W daylight fluorescent bulb,single high power 1W LED,white,light intensity adjustable
|
●
|
|
Bottom illumination:6V 30W halogen bulb ,philips 5761,light intensity adjustable
|
●
|
Note: ● Standard， ○ Optional
1pcs/ctn
Size:40*35*50
G.W.:6KGS N.W.:5KGS
|
