Optical
System
|
finite
Optical System 160mm
|
●
|
|
|
Viewing
Head
|
Seidentopf Binocular Viewing Head,
Inclined at 30º，Interpupillary
48mm-75mm
|
●
|
|
|
|
|
Eyepiece
|
Wide
Field Eyepiece WF10X/18mm
|
●
|
|
|
Wide
Field Eyepiece WF16X/13mm
|
○
|
|
|
Wide
Field Eyepiece WF20X/11mm
|
○
|
|
|
Objective
|
Finite
195 Series Achromatic Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
|
|
Nosepiece
|
Forward
Quadruple Nosepiece
|
●
|
|
|
Forward
Quintuple Nosepiece
|
○
|
|
|
Condenser
|
Abbe
Condenser NA1.25 with Diaphragm
|
●
|
|
|
|
|
Focusing
System
|
Coaxial
Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke36mm
|
●
|
|
|
|
|
Stage
|
Double
Layer Mechanical Stage 142x132mm , , Moving Range75mmx50mm
|
●
|
|
|
|
|
Illumination
|
External
Illumination, 3W/LED
|
●
|
|
|
Optional
Accessory
|
Seidentopf
Trinocular Viewing Head
|
○
|
|
|
C
Mount 0.5X
|
○
|
|
|
6V
20W Halogm Lamp
|
○
|
|
|
Product single size
|
30x20x38cm
|
●
|
|
