Optical System
|
Finite Optical System
|
●
|
|
|
|
|
Viewing Head
|
Seidentopf Trinocular Head，Inclined at 45º ，360ºRotatable
|
●
|
|
|
|
|
|
|
Eyepiece
|
Wide Field Eyepiece WF10X/20mm
|
●
|
|
|
Wide Field
Eyepiece WF16X/15mm
|
○
|
|
|
Wide Field Eyepiece WF20X/12mm
|
○
|
|
|
Objective
|
Finite 195 Series Achromatic
Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
|
|
Finite Plan Achromatic
Objectives CF 4X 10X 40Xs 100Xs(oil)
|
○
|
|
|
Nosepiece
|
Quadruple Nosepiece
|
●
|
|
|
Quintuple Nosepiece
|
○
|
|
|
Condenser
|
Abbe Condenser NA1.25 with Diaphragm，Filter
|
●
|
|
|
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment,
Fine Division 0.001mm, Coarse Stroke37.7mm/Rotation, Fine Stroke
0.1mm/Rotation, Moving range 24mm
|
●
|
|
|
|
|
Stage
|
Double Layer Mechanical Stage
142x132mm , , Moving Range75mmx50mm
|
●
|
|
|
|
|
Illumination
|
Illumination,3W/LEDAdjustment
|
●
|
|
