Viewing Head
|
Trinocular Head，Inclined at 45º ，360ºRotatable
|
●
|
|
|
|
|
|
|
Eyepiece
|
Wide Field
Eyepiece WF10X WF16
|
●
|
|
|
Wide Field Eyepiece WF20X
|
○
|
|
|
Objective
|
Achromatic
Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
|
|
Nosepiece
|
Quadruple
Nosepiece
|
●
|
|
|
Condenser
|
Abbe Condenser NA1.25 with Diaphragm，Filter
|
●
|
|
|
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment,
Moving Range 30mm
|
●
|
|
|
|
|
Stage
|
Double Layer Mechanical Stage
140x130mm , Moving Range75mmx45mm
|
●
|
|
|
|
|
Illumination
|
6V/20W
Halogm Lamp，Brightness
Adjustment
|
●
|
|
|
LED
Illumination，Brightness
Adjustment
|
○
|
|
|
Product
single size
|
22x20.5x42cm
|
●
|
|
