Viewing
Head
|
Monocular
Head, Inclined at 45º ，360ºRotatable
|
●
|
|
|
|
|
|
|
Eyepiece
|
Wide
Field Eyepiece WF10X/16mm
|
●
|
|
|
Wide
Field Eyepiece WF16X/13mm
|
○
|
|
|
Objective
|
Achromatic
Objectives 4X 10X 40Xs
|
●
|
|
|
|
|
|
|
Nosepiece
|
Quadruple
Nosepiece
|
○
|
|
|
Triple
Nosepiece
|
●
|
|
|
Condenser
|
Abbe
Condenser NA0.65 Disc Diaphragm
|
●
|
|
|
|
|
|
|
Focusing
System
|
Moving
Range 22mm, Adjustment Range 1.3mm
|
●
|
|
|
|
|
Stage
|
Plain
Stage with Slide Clips 120x130mm
|
●
|
|
|
|
|
|
|
Illumination
|
220V/20W
Incanaescent Lamp
|
●
|
|
|
LED
Illumination
|
○
|
|
|
Product
single size
|
20.5x12.5x35cm
|
●
|
|
