NP-EM003M-1

NP-EM003M-2

NP-EM003M-3

NP-EM003M-4

Viewing Head

Monocular Vertical Tube

●

●

●

●

Eyepiece

5X 10X

●

5X 10X 12.5X

●

5X 10X 15X

●

5X 10X 16X

●

Objective

10X 40Xs 100Xs(oil)

●

●

●

●

Nosepiece

Triple Nosepiece

●

●

●

●

Quadruple Nosepiece

○

○

○

○

Condenser

Abbe Condenser NA1.25 with  Iris Diaphragm，Filter

●

●

●

●

Focusing System

Coarse Adjustment Range 50mm

Fine Adjustment Range 1.8mm~2.2mm

●

●

●

●

Stage

Attachable Mechanical Stage 120x120mm

●

●

●

●

Illumination

Φ50mm Plan Reflector

●

●

●

●

110V/20W 220V/20W Incanaescent Lamp

○

○

○

○

Product single size

20x14x33cm

●

●

●

●
