Viewing Head
|
Monocular Head, Inclined at 45º ，360ºRotatable
|
●
|
|
|
|
|
|
|
Eyepiece
|
Wide Field Eyepiece WF10X/18mm
|
●
|
|
|
Wide Field Eyepiece WF16X/13mm
|
○
|
|
|
Objective
|
Achromatic Objectives 4X 10X 40Xs
|
●
|
|
|
|
|
|
|
Nosepiece
|
Quadruple Nosepiece
|
○
|
|
|
Triple Nosepiece
|
●
|
|
|
Condenser
|
Abbe Condenser NA0.65 Disc Diaphragm
|
●
|
|
|
|
|
|
|
Focusing System
|
Moving Range 22mm, Adjustment Range 1.3mm
|
●
|
|
|
|
|
Stage
|
Plain Stage with Slide Clips 127x132mm
|
●
|
|
|
|
|
|
|
Illumination
|
220V/20W Incanaescent Lamp
|
●
|
|
|
LED Illumination
|
○
|
|
|
Product single size
|
20.5x12.5x35cm
|
●
|
|
