Viewing Head
|
Monocular Vertical Tube
|
●
|
|
|
Eyepiece
|
5X 10X 15X
|
●
|
|
|
Objective
|
5X 10X 45Xs
|
●
|
|
|
Nosepiece
|
Triple Nosepiece
|
●
|
|
|
Quadruple Nosepiece
|
○
|
|
|
Condenser
|
Iris Diaphragm，Filter
|
●
|
|
|
|
|
Focusing System
|
Coarse Adjustment Range 50mm
Fine Adjustment Range 1.8mm~2.2mm
|
●
|
|
|
|
|
Stage
|
Φ120mm with Slide Clips
|
●
|
|
|
Illumination
|
Φ50mm Plan Reflectir
|
●
|
|
|
110V/20W 220V/20W Incanaescent
Lamp
|
○
|
|
|
Product single size
|
20x13x33cm
|
●
|
|
Note：● Standard Outfit ○ Optical
